Db Type Sic Heating Elements - China

The length of the silicon carbide rod heating section should be equal to the width of the furnace.

If the heat section into the furnace wall, easy to burn furnace wall.

3, the length of the cold end of the silicon carbide rod should be equal to the thickness of the furnace wall plus the length of the cold end of the furnace wall.

The generally cold end extends from 50 to 150 mm in length to cool the cold end and the connecting fixture.

4, wear silicon carbide rods should be the diameter of the cold end of the outer diameter of 1.4 to 1.6 times the furnace hole is too small or the hole stuffing too tight, high temperature will hinder the free expansion of silicon carbon rods lead to broken rod The Installation, should be able to make silicon carbon rods free to rotate 360 degrees.

5, silicon carbon rods and heated objects and the distance between the furnace wall should be greater than or equal to 3 times the diameter of the heating section.

The center distance between the silicon carbide rod and the silicon carbide rod shall be not less than four times the diameter of the heat generating portion.

6, silicon carbon rod cold end and the main circuit with aluminum braid or aluminum foil connection.

The cold end of the fixture to be clamped.
