Cm Quarter Turn Electric Actuator Cm200 - Taiwan

Specification:

Power：60W

Max Torque：200 N.

m/1771 lb.

in

Speed：22 Sec/90°

Weight：7.6 kg/17 lb

Mounting Flange(ISO 5211)：F07 Feature:

Enclosure:

● Base：Dry powder coated aluminum alloy.

● Top cover：ABS anti-collision plastic material.

Motor :

● B class insulation.

● Built-in thermal protection prevents motor burning out.

AC motor：115±5℃/239±9� �� DC motor：90±5℃/194±9� � Manual override device :

● Users can open or close the actuator with manual override device.

Please remove the red dust proof plug on the manual override device when manual operation is needed and put the red dust proof plug back after finishing the manual operation.

Duty Cycle :

● 30% duty cycle.

Position indicator : ● All models have a continuous mechanism position indicator on the top of actuator cover to indicate the valve's position.

Working Conditions : ● Ambient temperature：

Plastic cover -10℃~+65℃

Aluminum cover -30℃ ~ +65℃ / -22℉ ~ +149℉

●The humidity：30%~95% Conduit entrance

● Standard：1/2" PS

● Optional：3/4" NPT, 1/2" NPT, M20 Various voltage

● 24V AC/DC

● 110/220V 1-Phase

● 220/380/440V 3-Phase Aluminum cover(round shape)

● The option is suitable for outdoor applications.

Hand-wheel

● When using manual override device, user can choose the hand-wheel to operate the actuator easily as an option.

Manual power-off device

● When power is supplied, users can switch from "Auto"to"Manual"with a lever to operate the manual override device to either open or close direction.

Certification:

● IP 67 ● CE ● RoHs
