Product Name: X1, X2 Film Capacitor

Goods of Description :

CTX are non- inductively wound with a metallized Polypropylene film dielectric/ electrode, encapsulated in flame retardant ( UL94, V- 0) plastic case and epoxy resin end seal.

Features :

■ Provides interference suppression, all safety approval

■ Overvoltage stress withstanding

■ Self- healing properties

■ Active and passive flame retardent

Specification : Climate Category: In accordance with DIN40040 GMF

a) G=Minimum Limited Temperature….

- 40℃

b) M=Maximum Limited Temperature….

+110℃ .

c) F=Humidity Category…Average relative humidity≦ 75% , 95% for 30 days per year,

continuously: 85% for the remaining days, occasionally.

■ Rated Voltage: ………500/ 480/ 440/ 380/ 350/ 310/ 300 VAC, 50~60Hz

■ Capacitance Range: …………0.0047~1.0uF

■ Capacitance Tolerance: J( ±5% ) , K ( ±10% ) , M( ±20% )

Type : ■ Ideal for use in line bypass, antenna coupling, across- the- line and spark killer circuits.

■ Available for EMI filter.

■ Switching power supply applications.

■ Business machines appliances, such as: typewriters, adding machines, computer displays and monitors.

■ Household appliances, such as: mixers, fans, coffee grinders audio and TV circuits.

■ Thyristor and triac appliances, such as: dimmers.

Company Contact:

• Posted By: Cheng Tong-Chen Industrial Co., Ltd

• Phone: 88633631093

• Address: No.38, Lane 86, Sec.1, Jieshou Rd, Ba Teh city, Taoyuan Hsien, Taiwan

• Email:

• Website: http://www.chengtung.com.tw

• Business Description: My company, CT, was founded in 1998 - At present, CT have more than 18

  years experience in producing all kinds of high quality and reliability

  capacitors.



  CT is one of the leading suppliers of X1 and X2 safety capacitors and other type of polyester (polypropylene) capacitors.

  The features of capacitor include suppressing the noise from power source, electromagnetic interference (EMI), electromagnetic compatibility (EMC), to protect switch contact (spark elimination), antenna coupling and power line bypass etc.

  We have a lot of certifications of X1 and X2 Capacitors such as UL, CUL, ENEC, CQC, EK Mark and so on.

  Their voltage rates, 310V 330V 350V 380VAC etc, satisfy all kinds of products.

  Among of them, our 350VAC capacitors were awarded the first ENEC certification in the world issued by USA UL.

  CT s lead technology was obvious to everyone from the fact that Mr.

  Milan Dotlich, the UL Global Engineering director, represents UL to come to CT, Taiwan holding an awards ceremony in November 2013.
