Ceramic Capacitor 103 Manufacturers New Safety Capacitors - China

Product features:

Ceramic Capacitor 103 has wide working temperature range, low loss and high capacity stability.

Electrical characteristics:

Reference Standards: GB/T 2693-2001 ; GB/T 5966-1996 Rated Voltage(UR): 500 / 1K / 2K / 3K / 4K / 5K / 6K / 7K / 8K / 9K / 10K / 15K / 20K / 25K / 30K / 40K /50K VDC Capacitance Range: 1pF to 100000pF Capacitance Tolerance: NPO±0.5pF(D)±5%(J) ; SL±5%(J)±10%(K), Y5P, Y5U±10%(K ) ; Y5U, Y5V±20%(M) Insulation Resistance(IR): IR≥10000MΩ, 1min, 100VDC, IR≥4000MΩ, 1min, 100VDC Operating Temperature Range: -25℃ to +85℃ Temperature Characteristic: NPO, SL, Y5P, Y5U, Y5V Flame Retardant Epoxy Resin: UL94-V0 Application Area :

Ceramic Capacitor Application

1 - Apply to high-voltage bypass and coupling circuits, or the circuit responsible for line scanning in TV.

2 - Apply to tuning circuits or circuits that need to compensate for temperature effects.

3 - Apply to the circuits requiring large capacity, such as energy storage, memory circuits, etc.

Matters Needing Attention:

1 - Do not store the capacitor in corrosive gas, especially in the presence of chlorine, sulfur, acid, alkali, salt, moisture, etc.

2 - The storage temperature and the relative humidity should not be too low or too high.

Ceramic capacitor 103 can be applied to circuits requiring large capacitance, such as energy storage, memory circuits, etc.

If you need this product, please feel free to contact us!
