Rf Transceiver Cob Module Rfm66 - China

HOPERF has developed into the domestically first intact industry chain

group company integrating ASIC chip design, MEMS sensor chip design,

package test calibration technique and application services.

HOPERF owns

a top R & D design team with more than 80 persons globally and it has 16

years' experience in the industry, covered 33 countries and served for

1073 brand customers globally.

Application:

AMR Auto Meter Reading, Industrial Control System, Wireless Remote Control Equipment, Mining Safety Monitoring, Smart Home, Smart Security, Internet of Things and Other Wireless Devices, etc.

RF Advantages:

High output power, very good receiver sensitivity, long communication distance

Strong interference resistance to meet wireless certification standards

Meet the requirements of mainstream wireless applications, high cost- effective

No output power reduction at a supply voltage down to 1.8V

Parameter:

Frequency: 868/ 915MHz

Modulation Mode: FSK/ GFSK/ OOK

Output Power: 20dBm

Sensitivity: - 123dBm ( 1.2kb/ s in FSK)

Data Rate: 300Kbps ( FSK mode)

Tx Current: 125mA ( +20dBm)

Rx Current: 9.3mA

Standby Current: 0.1μ A

Interface: SPI

Communication Distance: > 1000m( 1.2kb/ s)

Antenna Impedance: 50Ω

Operation Temperature: - 40~+85

Power Supply Mode: DC1.8~3.7V, 1.8VTransmission power

Of power supply will not fall

Module Size: 16X16mm

Certifications:

FCC\ ETSI\ RoHS
