Unarmored Ex Cable Glands Shbdm 8 - China

Product Features：

1 - Suit for unarmored cable

2 - Materials: Brass, brass nickel planted and stainless steel 304, 316L

3 - Sealing ring materials; silicon rubber (-60℃- +180℃)

4 - It need with packing seal for explosion-proof.

5 - For District1, district2, 21area and 22area

1 - Explosion-proof mark: Exd IIC Gb / Exe II Gb / Ex tD A21 IP66

Specifications AG Thread Length GL Cable Range B Diagonal Metric NPT/G SHBDM-8-01 M16 3/8 15 7-15 46

SHBDM-8-02 M20 1/2 15 7-15 46

SHBDM-8-03 M25 3/4 15 14-21 47

SHBDM-8-04 M32 1 18 14-26 48

SHBDM-8-05 M40 1-1/4 18 19-33 57

SHBDM-8-06 M50 1-1/2 19 22-40 60

SHBDM-8-07 M63 2 21 29-50 65

SHBDM-8-08 M75 2-1/2 21 35-63 80
