Hdmi Extender Optical 300m Hdmi1 4v 4kx2k 3d 1080p 120hz - China

This YT- HDT1R1300M HDMI Optical fiber extender use single Twin- core

multimode LC- LC fiber can reach HD signals 300m, and make sure it

support Full HD 1080P, 4K* 2K, 3D signal.

It has broken the distance

limitation of HDMI cable and more flexible.

In order to save customers'

cost, our company offer solutions for HD signals transmit conditions,

for example some place the transmit distance has limitation, broadcast,

data control center, information share center, showing room, plaza

advertisement, train platform, airplane, shopping mall etc.

Advantages:

1 - HDMI cable the distance is not flexible, and need professional workers, the customer can' t change the distance easily.

But our system is according to the environment.

2 - If customer plan to fix the HDMI cable in the inner pipe, because HDMI connector is bigger, it is hard to Elongation and shortening.

3 - Because this system use optical fiber as the transmission medium, it can reach 300m and the signal support Full HD 1080P, , 4K* 2K, 3D.

But HDMI cable is not able to.

Features:

1 - Long distance and low power consumption.

No signal loss, set up rather easy.

2 - Multimode, twin- core fiber, 850nm, double LC- LC interface, 10G, 50/ 125um,

LC- LC high interface roughness- - OM3 optical fiber patch cord instead of HDMI

cable, reach 300m;

3 - Optical fiber, multimode, twin- core fiber interface;

4 - Meet EEE802.3ae, 10GBASE- SR connection standard.

5 - Auto adjust feedback information, no need worry about the length.

6 - Wave length rate: 850nm- 1310nm

7 - Support HDCP protocol, HDMI 1.4A, support DDC CEC HPD

8 - Support high resolution 1080P/ 60Hz, 4K* 2K* 30Hz, 3D

9 - Support 340Hz/ 10Gbps/ frame( total 10.3Gbps) bandwidth

10 - Support 36\ 48bit( total 48bit) deep color

11 - Audio format: DTS- HD/ Dolby- true HD/ LPCM7.1/ DTS/ DOLBY- AC3/ DSD/ HD( HBR)

SpecificationYT- HDT1R1300M

1 - Signal input.

.

.

.

.

.

HDMI1.4 A compatible

2 - Video Output.

HDMI1.4 A compatible

3 - HDMI Resolution.

.

.

.

.

.

.

Full HD 1080P60Hz, 3D, 4K* 2K* 30HZ

4 - Audio format .

.

DTS- HD/ Dolby- trueHD/ LPCM7.1/ DTS/ DOLBY- AC3/ DSD/ HD( HBR)

5 - Max Extend distance.

300M

6 - Video enlarge bandwidth.

10.2Gbps/ 340MHz

7 - Frequency Range.

24/ 25/ 30/ 50/ 60/ 120Hz

8 - Size( L* W* H) .

80x20x9 mm

9 - Net weight.

0.1kg* 2

10 - Operating Temperature range.

+/ - 5℃ to +70℃

11 - Operating Humidity range5% to 95 % RH ( no condensation)

12 - Power adapterDC 5V/ 2A

13 - Max power…5W
