Gigabit Transformer Modules With Power Over Ethernet Option Trc6062anl - China
price: 0.45 Dollar US$
Gigabit Transformer Modules
Single Port
24pin Soic with PoE option
Isolation Voltage: 1500Vrms
Temperature: 0 TO 70
UL, RoHs, Reach, ISO9001: 2008
Free sample supported for testing
1 - Designed to support application, such as SOHO (ADSL modems), Lan-on-Motherboard(LOM), hub and switches.
2 - Meets IEEE 802.3 specification.
3 - Maximum reflow temperature is 260℃, 5 Sec.
4 - UL certification: File Number E321120
ELECTRICAL APECIFICATIONS @25℃
1 - Turn Ratio(±2%)
TX=1CT: 1CT RX=1CT: 1CT
2 - Inductance OCL:
350uH MIN @ 100KHz 0.1V 8mA DC Bias
3 - Insertion Loss:
-1.1dB MAC @ 1-100MHz
4 - Return Loss:
-16dB MIN @ 1-30MHz
-12dB MIN @30-60MHz
-10dB MIN @ 60-100MHz
5 - Cross talk:
-40dB MIN @ 1-30MHz
-35dB MIN @30-60MHz
-30dB MIN @60-100MHz
6 - Differential to common Mode Rejection(dB TYP):
-30dB MIN @ 1-50MHz
-20dB MIN @50-150MHz
7 - Balances DC Line current:
350mA MAX @ 48VDS Continuous.
8 - Hipot Test: 1500Vrms
9 - Operation Temperature Range: -40 ℃ TO +85℃
Company Contact:
- Posted By: Shenzhen Trxcom Electronics Co.,Ltd
- Phone: 86--13554918626
- Address: 4/F,3 BLDG,No.3 Industrial Zone,Minzhi Villiage,Longhua Town,, shenzhen , Guangdong , China
- Email:
Published date: August 23, 2016
- Business Description: Trxcom is the leading manufacturer of RJ45 connector with magnetic, Lan Transformer, Audio transformer.
The products are widely used in networking and communication equipments such as HUB, PC card, Switch, Route, PC Mainboard, SDH, PDH, IP Phone, Xdsl Modem.
1) 10/100/1000M LAN pulse transformer and filter
2) RJ45 connector with 10/100/1000M magnetic
3) T1/E1, T3/DS3/E3 - STS-1 interface line transformer
4) ISDN, HDSL, ADSL and VDSL interface line transformer and splitter
