Startup System Training Panel - China

i.

About The Product The device is designed based on the Volkswagen Jetta 1.6 system to holistically demonstrate the structure and operation of the startup system.

The device applies to theoretical teaching and maintenance training of the startup system in secondary and senior vocational skill schools, normal education and training institutions.

ii.

Features 1 - A real and operable startup system is used to illustrate the structure of the system.

2 - An ignition switch can be operated to start up the motor.

In this way, the device demonstrates operation of the startup system.

The training panel is installed with an ammeter and a voltmeter that respectively display changes of the starting current and accumulator voltage.

3 - The training panel is made of advanced aluminum-plastic plate with characteristics of not less than 4mm thick, corrosion resistance, impact resistance, pollution resistance, fireproof, and moistureproof.

Its surface are processed by special craft and spraying primer.

Never fade color circuit diagram and working principal diagram are painted on the board whose surface coating with varnish.

The trainees can learn and analyze the working principle of the control system by referencing the diagram and the real object.

4 - The training panel is installed with components of the starter assembly, enabling trainees to easily understand the structure of the starter.

5 - The training panel is installed with detection terminals to detect electric signals, for example, resistance, voltage, current, and frequency, of circuit components of the startup system.

6 - The training panel's base frame is made of steel and the surface is paint-coated.

Self-retention wheels are installed and 2a 4 0cm tabletop is fixed on the base frame to place materials and light testing devices.

7 - Equipped with intelligent fault setting and appraisal system, which can connect to the network, fault settings, troubleshooting, parameter setting, remote starter, information feedback, assessment score through the main control computer iii.

Basic Parameter 1 - Size: 1600mm × 700mm × 1700mm (length x width x height) 2 - External power supply: A.C. 220V ± 10% 50Hz 3 - Operating voltage: 12V DC 4 - Operating temperature: -40℃ to +50℃
