Led Linear Light Ll Ac - China

LED Linear Light LL-AC dimmable LED Linear Light for sale Customized LED Linear Light supplier

Model: JST-LL-AC

Wattage: 2W-30W

LED Chip: OSRAM3030

Driver Brand: OSRAM/Philips/Lifud

RA: ＞90

Finish Color: White/Black/Customized


Beam Angle: 15°/30°/45°

Diameter: 45mm-412mm

Cutout: 37mm-405mm

Customized LED Linear Light Description

LED Linear Light LLA Series the lamp body, in fashionable design, is made of 6063 section aluminum and PC reflector.

It is combined LED lighting with building harmoniously.

Creat a circle of light from a line of LED downlights, A narrow line of nano LED downlights for pure minimalism, three choices of beam angle 15°/30°/45°, Brilliant quality, more than 50, 000 hours life span.

dimmable LED Linear Light Advantages

1 - High brightness, low light decline

2 - Owns unique and attractive design

3 - Creat a circle of light from a line of LED downlight

4 - A narrow line of nano LED downlights for pure minimalism

5 - Superior glare control for high performance and visual comfort

6 - The installation is easy and safe

LED Linear Light Specification

Model Power CRI CCT PF Current Input Voltage Beam Angle Dimension Cutout

JST-LL-AC 2W >80/90 2700K-5000K >0.65 0.05A AC220-240V 15°/30°/45° L45*W45*H49mm L37*W37mm

JST-LL-AC 4W >80/90 2700K-5000K >0.65 0.60A AC220-240V 15°/30°/45° L75*W45*H49mm L68*W37mm

JST-LL-AC 10W >80/90 2700K-5000K >0.65 0.60A AC220-240V 15°/30°/45° L147*W45*H49mm L140*W37mm

JST-LL-AC 20W >80/90 2700K-5000K >0.90 0.60A AC220-240V 15°/30°/45° L280*W45*H49mm L273*W37mm

JST-LL-AC 30W >80/90 2700K-5000K >0.90 0.60A AC220-240V 15°/30°/45° L412.7*W45*4H9mm L405*W37mm Long lifespan LED Linear Light Application

Fashion stores, Stations, Hotels, Offices, Shopping malls, Clubs, Supermarkets etc.
