HD Digital cable receiver DVB-C 800C

300 MHz MIPS Processor

Linux Operating System

Tuner: DVB-S, optional: DVB-C, DVB-T

- OLED Display

- MPEG-2 / H.

264 Hardware decoding

- Tuner: DVB-S, optional: DVB-C, DVB-T

- Tuner Module, Plug&Play

- 1 x Smartcard-Reader

- V.

24/RS232 Interface

- 10/100Mbit Ethernet Interface

- 1 x Scart (RGB, FBAS or S-Video)

- DVI

- 2 x USB 2.0

- analog modem

- S/PDIF Interface for digital bit stream out (AC-3)

- 64 MByte Flash, 256 MByte RAM

- SATA

- for use either as internal SATA HDD 2, 5

- or to use for extern eSATA

- unlimited channel lists for TV/Radio

- channel-change time < 1 second

- automatic service scan

- directly bouquet-lists

- EPG (electronic program guide)

- multiple LNB-Switching control (supports DiSEqC)

- OSD in many languages and skin-support

- Videotext Decoder

- extern 12V power supply

DBS-Tuner mit DVB-S2:

Frequency Range 950.2150 MHz

Demodulation DVB-S (QPSK); DVB-S2 (8PSK, QPSK)

Symbol rate DVB-S: 2.45 Mbaud/s, SCPC/ MCPC

DVB-S2: 10 31 Mbaud/s (8PSK), 10 30 Mbaud/s (QPSK)

Video decoder:

Video Compression MPEG-2 and MPEG-1 compatible, H.

246

Video Formats 4: 3 / 16: 9

Letterbox for 4: 3 TV-Device

Audio decoder:

Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3

Audio Mode Dual (main/sub), Stereo

Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz

Output analog:

Output Level L/R 0, 5 Vss on 600 Ohm

THD > 60 dB (1 kHz)

Crosstalk < -65 dB

Output digital:

Output Level 0, 5 Vss on 75 Ohm

Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz

S/PDIF-Output optical, Toslink

Ausgang Video:

Ausgangspegel FBAS 1 Vss +/- 0.3 dB an 75 Ohm

Video parameter:

Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm

Teletext filter in conformity with ETS 300 472 Standard

TV-Scart:

Output: FBAS, RGB, S-Video

Serielle Interface RS 232:

Typ RS232 bidirectional

Bitrate 115, 2 kBit/s max.

Plug Connector SUB-D-9

Function: Update of Firmware

Ethernet:

10/100 MBit compatible interface

Function: Update of Firmware

Analoge modem:

Analoge modem for Internet connection

SATA Interface:

- for use either as internal HDD 2, 5 or eSATAor internal 2, 5" HDD

USB

2 x USB 2.0 Host

LNB power and polarisation per tuner:

LNB Current 500mA max.

; Short-circuit-protected

LNB Voltage vertical < 14V no load, > 11, 5V at 400mA

LNB Voltage horizontal < 20V no load, > 17, 3V at 400mA

Count of active satellite position:

DiSEqC 1.0/1.2 SAT POSITION / SAT OPTION

DiSEqC - Rotor Control

Power consumption:

< 15W at 12V

External PSU

Input:

110-240V AC / 50-60Hz / 0, 6A

Output:

12V = / 3, 0A

Physical specification:

Ambient Temperature +15° C.

+35° C

Humidity < 80%

Without HDD
