High Flow Rate Water Spun Sediment Filter Cartridge - China

10'', 20'', 30'', 40'' PP sediment water filter cartridge Features & Benefits A.

Depth filter cartridges is constructed of quality polypropylene filter media to ensure high efficiency in the inner layer bonded micro-fiber construction offers no fiber release and consistent flow rates as well as superior filtration performance B.

High dirt holding capacity.

C.

Materials are FDA listed as acceptable for potable and edible;Available in a wide selection of micron rating from 1µm to 100µm Applications

• Drinking water treatment • Pre-filtration for RO+DI • Food and beverage • Plating, Chemicals and Solvents Specifications

• Material : 100% PP microfiber • Micron rating: 1, 3, 5, 10, .

100um • OD.

61-65mm/110-115mm; ID.

28mm • Length: 5", 10", 20", 30", 40", 50", 60"

Operating Conditions

• Maximum differential pressure: 4.1bar at 20℃; 2.1bar at 60℃; 1.1bar at 80℃ • Recommended change out: 2.0bar • Maximum temperature: 80℃

Dirt Holding Capacity

•Micron Rating(μm) ; 1, 3, 5, 10, 25, 50 •Dirt Holding Capacity(Gram/10"L); >15 >20 >30 >60 >120 >150
