12v200ah Gel Battery Solar System - China

Specification

Nominal Voltage 12V

Nominal Capacity (20HR) 200.0AH

Product Series GEL

Dimensions Length 522±2mm(20.5inches) Width 240±2mm(9.44inches) Container Height 219±3mm(8.61inches) Total Height(with Terminal) 227±3mm(8.93inches)

Approx Weight 60.0kg/132.0lbs

Terminal M6-16/M8-16

Rated Capacity 200AH/10.0A (20HR, 10.80V, 25℃/77℉) 190AH/19.0A (10HR, 10.80V, 25℃/77℉) 160AH/32.0A (5HR, 10.80V, 25℃/77℉) 140AH/46.6A (3HR, 10.80V, 25℃/77℉) 120AH/120A (1HR, 10.20V, 25℃/77℉)

Max.

Discharge Current 1800A(5s)

Internal Resistance Approx 2mΩ

Operating Temp.

Range Discharge: -35~50℃(5~122℉) Charge: -20~40℃(32~104℉) Storage: -45~40℃(5~104℉)

Nominal Operating Temp.

Range 25±3℃(77±5℉)

Cycle Use Initial Charging Current less than 60.0A.

Voltage 14.6V~14.9V at 25℃(77℉) Temp.

Coefficient -5mV/℃

Standby Use Initial Charging Current less than 60.0A Voltage 13.6V~13.9V at 25℃(77℉) Temp.

Coefficient -3mV/℃

Capacity affected

by Temperature 40℃ 104℉ 103% 25℃ 77℉ 100% 0℃ 32℉ 95%

Self Discharge Xbatt GEL series batteries may be stored for up to 12 months at25℃(77℉) and then a freshening charge is required.

For higher temperatures the time interval will be shorter

Design Life 15 years
