Container House Gz Cth 1011 - China

Container house: The container house is movable as a whole

unity.

This kind of container house is reusable usually as

offices in domestic areas other than as habitable houses.

Using a kind of 1150 modulus design, with security nets,

doors and floor tile, it‘s firm and safe.

Cabinet unit

structure for the introduction of steel and cold-formed

steel welded together to make up standard components.

The

container house can be designed just as just one unit or

connected to a whole from several boxes, by simple

connection such as bolts.

Easy to assemble

Floor beam: main beam is 14a U-steel and secondary beam is

U70*50*2.0 bending steel made of Q235 galvanized material

Roof beam: main beam is 16a U-steel and secondary beam is

Z60*60*2.0 bending steel made of Q235 galvanized material

Steel frame: 100*4mm rectangle tube made of Q235 galvanized

steel

Wall panel: 50mm double-faced colored steel sandwich board

Roof panel: 0.426mm colored steel single board

Insulation: 50mm glass wool for roof; 60mm polystyrene for

wall

Design specification:

Roof load: 1.0KN/㎡

Wind load: 32m/s

Ground Load: 3.0KN/㎡

Seismic resistance: magnitudes 8

Empty Weight: 2000kg including packing
