Pet Surface Panel - China

PET PANELS offers excentllent value and consistent quality in high-gloss and supper matte components .

The high gloss surface is created by using the highest quality imported PET film (highest tempature and uv resistance )applied over a melamine board

OSB PET Surface Panel Size 1220*2440 MM 1220*2750 mm, 1220*3050 Thickness 5, 6, 9, 12, 15, 16, 18, 25mm

Core MDF, HDF, Plywood, OSB, Particle board, PVC Foam board ETc

Hardness 2H

Surface finishing Imported PET Sheet

Adhesive Germany brand hot-melt- glue

Back finishing White or matching color high quality melamine

Color Solid color, wood grain color, Aluminum, texture

MDF PET Surface Panel Description

Plywood PET Surface Panel paramaters

Index Unit Test Result Test Method High gloss Supper Matt High gloss / >92 <5 60 glossy meter

Tensile strength Machine Direction kg/cm3 ≧400 ≧400 DIN EN ISO 527-1 kg/cm3 ≧350 ≧350 Tear Strength Transvere Direction kg/cm3 ≧100 ≧100 DIN EN ISO 527-1 kg/cm3 ≧100 ≧100 Scratch-resistance Class 4F 4F DIN68861-4

Abrasion Class 2A 2A DIN68861-2

UV resistance Grey scale 5 5 IS04892-2

Chemical resistance Class 1B 1B DIN 68861-1

Wet heat resistance Class 8B (70 ℃) 8B (70 ℃) DIN68861-8

Dry heat resistance Class 7D(70 ℃) 7D(70 ℃) DIN68861-7

More information can view here.

Company Contact:

• Posted By: Shanghai Setting Decorating Material Co,.Ltd.

• Phone: 13611708566

• Address: No.185 fengguo Rd Fengcheng Twon ,Fengxian district Shanghai China , shanghai , shanghai , China

• Email:

• Website: https://www.settingboard.com/

• Business Description: Shanghai Setting Decorating material Co,.

  Ltd is one of the first manfucturer who focus on the production of eco-friendly decorating panels.

  Our factory located in Shanghai which is the economy center of China.

  And covers area more than 10000 square meters with the annual production capacity more than 1.5 million square meters.

  We have passed ISO quality certificate .

  SETTING is the professional and energetic manufacturer with standardization management.

  Since established in 2005，SETTING Always insisit on introduce advanced equipment and technology ,keep innovation .

  Taking “healthy & eco-friendly ,stable quality ,intimate service and innovation “as our faith ,After the remitting effort of SETTINGS.

  SETTING high quality decorating panels has become the highly influential and competitive brand.

  SETTING main products : Imported PET surface panels , acrylic surface panels mainly apply to Kitchen cabinet , Bathroom cabinet , Wardrobe TV cabinet ,Sliding door ,Display cabinet , Wall panels and hotel furniture Etc.
