Electroplated Diamond Grinding Wheel For Non Ferrous Industry Application Miya - China

Name: electroplated diamond & CBN grinding wheel for non-ferrous industry application

No dressing, Body can be re-plated several times Introduction: Electroplate d diamond and Cubic Boron Nitride (CBN) tools are made up of a basic single layer or multi-layers (depending on application) of either diamond or CBN particles that are bonded to the tool surface using a nickel matrix.

The product can be made with various shapes and they are suitable for special complicated profile, surface grinding, Internal grinding, Slot grinding, Profile grinding and small and others form grinding.

Electroplated diamond and CBN tools are used for surface grinding, Internal grinding, Slot grinding, Profile grinding Ceramics, Glass, Tungsten Carbide, Ferrite, Chilled Cast Iron, Founded Alloy Steel, Titanium Alloy And etc

Applications of electroplated bond grinding wheels:

diamond tools for non - ferrous industry application

* carbide (grinding green and sintered tungsten carbide)

* ceramic (grinding ceramics like SIC, AJO, ZrO, etc)

* automotive (grinding brake liners and cutting re-enforced rubber mouldings)

* pharmaceutical (grinding factitious knee joint)

* dental (profiling rubber bonded grinding pins)

* ferrite (grinding magnetic parts)

* chemical (grinding laboratory glass)

* graphite (grinding graphite parts)

* glass (grinding tubes, automotive components)

* Fiberglass, Plastics and Electronic components, etc The Specification Of electroplated bond grinding wheels: Diameter(mm) Hole(mm) Blank thickness(mm) Return width Grit size Maximum RPM

16 3 0.3 5 200 20, 000

19 3 0.3 5 200 20, 000

20 3 0.3 6 200 20, 000

22 1.8 or 3 0.3 7 200 20, 000

25 2 or 3 0.3 9 200 20, 000

30 3 0.3 11 200 20, 000

38 3 0.3 11 200 20, 000

40 3 0.5 12 150 20, 000

45 3 0.3 17 150 20, 000

50 3 0.5 17 150 20, 000 Advantages of electroplated diamond & CBN wheels:

1 - No dressing procedure necessary, Body can be re-plated several times

2 - High geometric and proportion precision, Complicated forming

3 - retain their original shape and dimensions throughout their working life

4 - Simple electroplated process, less investment convenient manufacturing

5 - Excellent surface roughness, high grinding efficiency, long tool life

6 - free-faster cutting, no dressing, less heating due to the diamond particles protruding from the surface.

Please don't hesitate to contact me if you have any needs: miya AT moresuperhard.

com

Company Contact:

• Posted By: moresuperhard

• Phone: 18614972607

• Address: B906, Wanda Plaza, Zhongyuan Road, Zhengzhou, Henan , China, zhengzhou , henan , China

• Email:

• Website: https://www.moresuperhard.com

• Business Description: "Henan More Super Hard Products Co., Ltd" is specialized in manufacturing and marketing of diamond & CBN tools.

  We devoted to offer diamond & CBN tools following customer special specification of FEPA standard.

  Over 800 customers benefit from our skills of development, manufacture and application, They find a to make the grinding and cutting high efficiency, high precision, and better economy.
