Calcium Sulphate Raised Access Floor - China

Hpl 1.2 calcium sulphate raised floor model no: hdg.

600.32 - zg

panel size: 600×600×32/30mm / 610×610×32/30mm

finished material: hpl1.2mm / pvc2.0mm

core: calcium sulphate 30mm

back plate: galvanized steel 0.5mm

edge trim: abs edge band 0.6mm pedestal system:

t type column track: alloy aluminum 3600×56×(30+8)mm

stringer: galvanized steel 550×30×20mm

tube: galvanized steel 240×32×2.5mm

screwing bolt: m16×120mm

up plate: 102×60×2.5mm

down plate: 130×2.5mm

weight: 20kgs/pc

ffh: 150mm-1500mm

normal adjustable height: 300mm±20mm parameter reference:

certificate: iso9001/iso14001/ce: en128 25

international standard: fs1250

anti-static resistance 106~1010Ω

concentrated load ≥5560n (567kg)

rolling load ≥4450n

ultimate load ≥16680n

distribution load ≥33000n/sqm

fireproof incombustible a-1

wear performance ≥3000r

weight load ≥2000kgs feature & advantages:

waterproof

anti-corrosion

anti-slip

heat insulation

mechanic performance

integral stability

installation convenience

moving legs

avoiding pipes easily paving side, slope & corner

labor saving

material saving

non-deformation

smooth & steady

stronger loading

satety

durable

statistic

environment protection

quality guarantee 10 years to lifetime

beijing easypop computer room equipment ltd dedicated to produce hpl 1.2 calcium sulphate raised floor, pvc2.0 calcium sulphate raised floor, aluminum alloy column track pedestal.

hpl 1.2 calcium sulphate raised floor, pvc2.0 calcium sulphate raised floor, aluminum alloy column track pedestal supplier china, hpl 1.2 calcium sulphate raised floor, pvc2.0 calcium sulphate raised floor, aluminum alloy column track pedestal supplier

Company Contact:

• Posted By: Beijing EASYPOP Computer Room Equipment Ltd

• Phone: 18601113859

• Address: B207, Kaichi Building, Daxing Industrial Area, Beijing 100162 China, beijing , beijing , China

• Email:

• Business Description: Raised Floor System, Calcium Sulphate Raised Access Floor, Tempered Glass Raised Floor China, Raised Access Flooring Contractors

  Raised Floor Systems, also known as Access Floors, are an elevated structural floor that is stabilized over a solid substrate, typically a concrete slab.

  A raised floor system creates a gap ideal for running electrical wiring and HVAC ducts.

  The material of Calcium Sulphate and Tempered Glass is most common.
