Low Price New Crawler Dozer With Cummins Engine Sd8b - China

SD8B bulldozer is track-type dozer with

elevated sprocket, hydraulic direct drive,

semi-rigid suspended and hydraulic controls.

Equipped with power separating hydraulic-

mechanic type Torque converter, planetary,

power shift and one lever control

transmission.

SD8B bulldozer equipped with

integrated hydraulic system, electric

monitoring, SD8B bulldozer can be equipped

with many optional equipment and attachment,

it can be used in road building, hydro-

electric construction, land clearance, port

and mine development and other construction

field.

Specifications

Dozer

Tilt

Operation weight (including ripper) (Kg)

37400

Ground pressure(including ripper) (KPa)

93

Track gauge(mm)

2083

Gradient

30°/25°

Min.

ground clearance (mm)

556

Dozing capacity (m³)

11.38

Blade width (mm)

3940

Max.

digging depth (mm)

582

Overall dimensions (mm) 7751×3940×3549

Engine

Type

cummins NT855-C360S10

Rated revolution (rpm)

2100

Flywheel power (KW/HP)

235/320

Torque storage coefficient

20%

Undercarriage system

Type The track is

triangle shape.

The sprocket is

elevated elastic suspended.



Number of track rollers (each side)

8

Pitch (mm)

226

Width of shoe (mm)

560

Gear 1st 2nd

3rd

Forward (Km/h) 0-3.5 0-6.2

0-10.8

Backward (Km/h) 0-4.7 0-8.1

0-13.9

Implement hydraulic system

Max.

system pressure (MPa)

22.5

Pump type

Gears oil pump

System output L/min

220

Driving system

Torque converter Torque converter is

power separating hydraulic-mechanic type

Transmission Planetary, power shift

transmission with three speeds forward and

three speeds reverse, speed and direction can

be quickly shifted.

Steering clutch.

The steering clutch is

hydraulic pressed, usually separated clutch.

Braking clutch The braking clutch is

pressed by spring, separated hydraulic,

meshed type.

Final drive The final drive is two-

stage planetary reduction gear mechanism,

splash lubrication.
