Sl52 Sl62 Sl72 Sl82 Sl92 Sl102 Sl81 Square Reinforcing Mesh - China

price: contact company for price

Sl52/sl62/sl72/sl82/sl92/ sl102/sl81 square reinforcing mesh

galvanized mesh

reinforcing mesh was made by deformed bar after drawn, which is accorded to australian/new zealand standard as-nzs 4671-2001 - the material is 250n, 300e, 500l, 500n and 500e, the mesh spaces is 200mm, there is two sides overhang which is 100mm.

the steel bar after drawing shape as below figure:

1 - the angle of the rib or inclined indentation of the reinforcing mesh panels' bar isn't less than 45°.

the angle scope is greater than 45° and is less than 70°, the rib height is from 0.025d to 0.10d.

2 - the reinforcing mesh panel includes transverse and longitudinal bar, pitch and overhang.

the australian and new zealand's market, the normal panel size is 2.4m*6m.

because of containers size, we always advise our cutomer to make the panel size to be 2.2m*5.8m.

it can be easy to be load and save more usd1000 per container for packing and loading cost.

3 - each sheet of reinforcing mesh panel shall include number of bars, pitch, length, width, and overhang dimensions.

and the bar arrangement of reinforcing mesh panel has single bars, twin bars or combination of single bars and twin bars.

4 - the technical data of low price reinforcing mesh panel is contained composition and characteristic mechanical porperties of reinforcing steels.

we are square reinforcing mesh exporter.

how can we conctrol our products quality for exporting autralia?

firstly, we purchase the material from steel factory and inspect chemical composition and mechnical property of reinforcing mesh panel in our in-house laboratary according to as 1554.3.

secondly, the panel size tolerances meassure way as:

notes:

1 - grade 250n is supplied as plain round reinforcing steel complying with as 3679 - 1, exceptthe tolerance of the diameter and roundness dosen't apply it.

2 - for 500l steel bars, only requriement for wire diameter is less than 5.0mm is rekl≥500

a.

panel size dimensions≤6m in length, there is 40mm tolerances.

b.

panel size dimensions>6m in length, the tolerance is ±0.7%

c.

wire diameter and mesh size measure and weld shear resistance test conformance to as nzs 4761-2001 and as per contract.

d.

weigh the each bundle weight to calculate each panel weight.


Company Contact:


  • Phone: 86-311-80768128

  • Address: Chang'an District, Shijiazhuang , Hebei , China

  • Email: Email


Published date: March 6, 2020

  • Business Description: Heyou Wire Mesh was established in 2009 year, which is a professional manufactory for reinforcement mesh, reinforcing mesh, reinforced mesh.

    Heyou Wire Mesh can produce National Standard reinforcing mesh, Australian/New Zealand Standard AS-NZS4671-2001 Reinforcement Mesh, British Standard BS4483 fabric reinforcement/reinforced mesh, Osterreichische Norm B4200-7 Grids and reinforcing meshes, Germany Standard DIN488 SD Reinforcing Mesh, Normes Francaises NFA35-016 Steel Rebar Mesh and Swiss Standard SIA 16211 S550 Reinforcement Wire Mesh.

    Our production capacity is 2000tons per month.

    Heyou factory has 8 workshops and covers 20000sqm area, with advanced international standard production line and equipments.
