Platform Steel Grating - China
price: 15.00 Dollar US$
Steel grating is flat steel bar according to a certain distance and cross arranged and welded into the middle of a square lattice with an iron and steel products, steel grating generally use carbon steel production, appearance of hot dip galvanized, can serve to prevent the role of oxidation, can also be made of stainless steel .
1) Bearing Bar (Load Bar) Specifications (mm):
The specification of plain type and serrated type bearing bar is 25 x 3 to 100 x 8; The specification of I-section type is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4, etc.
2) Bearing Bar Pitch (center to center):
12.5, 25, 30, 30.16, 32.5, 34, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm etc, also be according to client's requirement and 30, 40, 60mm are recommended, America standard is available <1'' x 3/16'', 1 1/4'' x 3/16'', 1-1/2'' x 3/16'', 1'' x 1/4'', 1-1/4'' x 1/4'', 1 1/2'' x 1/4''(19-w-4) and so on.
> 3) Material:
Mild Steel (Low Carbon Steel) or Stainless Steel 4) Surface Treatment:
Untreated, Painting or Hot DIP Galvanizing 5) Steel grating standards:
A) China: YB/T4001-1998
B) USA: ANSI/NAAMM (MBG531-88)
C) UK: BS4592-1987
D) Australia: AS1657-1985
E) Japan: JJS
Company Contact:
- Posted By: Hebei weijia Metal Mesh Co.,Ltd
- Phone: +8615203189292
- Address: No.212 Jianhua Street, Shijiazhuang , Hebei , China
- Email:
- Website: http://www.wjmetalmesh.com
Published date: May 5, 2019
- Business Description: Hebei Weijia Metal Mesh Co.,Ltd is located in Hebei Province,is a research,development,prod uction,sales and service of high-tech enterprises.
Factory covers an area of 50 acres and currently employs more than 500 people,professional and technical personnel and more than 20 senior engineers,with a perfect organization,is a major producer of steel grating serious,steel fence serious,metal mesh serious of professional manufacturers.
