Clear Laminated Glass Architectural - China

Characteristics：

Laminated glass is characterized by transparency, superior mechanical strength, heat resistance, moisture resistance and cold resistance.

Compared with common glass, it has superior performance in safety, security, noise insulation and radiation resistance.

1, Extremely high safety and security: With excellent performance in earthquake resistance, shock resistance, penetration resistance, wind pressure resistance and strong PVB adhesion, laminated glass will not result in bodily injury from splashing splinters when it is struck and broken due to external force; it can withstand the attack of burglar's tools, such as hammer and brick.

It can improve the penetration resistance by increasing the thickness of the PVB film.

2, Good Acoustic Insulating Performance: PVB film can effectively absorb sound waves and reduce noise pollution;

3, Anti-UV linearity: without loss of visible light at the same time, it can effectively block nearly 99% of the UV into the house and prevent the interior decorations and furniture from fading and aging.

4, Color diversity: according to the needs of customers to produce a variety of colors or patterns of products to meet the engineering design requirements;

5, Thermal Insulating Performance: effectively block the heat transfer, reduce heat transmission, reduce cooling energy consumption;

6, Ballistic performance: through the different thickness of the PVB and the combination of several pieces of glass, it can be made of bullet-proof glass and some high-strength decorative glass or engineering structure glass;

Production Capacity:

Maximum specification: 3600×18000mm;

Minimum specification: 300 × 300mm

PVB film thickness: 0.38mm, 0.76mm, 1.14mm, 1.52mm and 2.28mm;

Total thickness of laminated glass: 2.78~100mm;

Color：white, gray, tan, green, blue, other color

Output: 2.5 million m²/year

Orders out of above specifications are negotiable.

Company Contact:

• Posted By: Qingdao Pioneer Glass

• Phone: 0532-86880938

• Address: East Kunlunshan Road, Taihangshan Road, Qingdao , State , China

• Email:

• Website: http://www.qdpioneerglass.com

• Business Description: Qingdao Pioneer Glass Co., Ltd is located in the beautiful Huangdao District, Qingdao.

  It is adjacent to the Qingdao Port and the Merchants International Terminal to the south and to the Tongsan and Jiaozhou Bay Expressway to the west and contiguous with Qingdao float glass base of Saint-Gobain Glass (France), Qingdao float glass base of Taiwan Glass and Qingdao patterned glass base of Jinjing Glass.

  It is convenient in traffic and predominant in geographical position.

  As an integrated intensive glass processing enterprise, it is specialized in the production and processing of laminated glass, tempered glass, Insulating glass, glass mirror, decorative safety glass and special glass.

  Our Products:

  - tempered, common laminated glass

  - decorative safety glass

  - mirror glass

  - flat tempered glass

  - bulkhead embedded insulating glass
