Hcipc P131 3 Adddip 150a 150w Dc Atx Computer Powersupply - China

◆ Dimensions (MM): L156 × W44.8 × H17

◆ Input voltage: +18 V / DC - +24 V / DC

◆ Output Power: 130W

◆ Efficiency: > = 92%

◆ Operating temperature: 0 ℃ ~ 40 ℃

◆ Storage Temperature: -20 ℃ ~ 80 ℃

◆ Output electrical characteristic Votage Min(V) Max(V) Min(A) Max(A) Ripple(mV) Line SCP

+12V 11.40 12.60 0 6 120MAX yellow SPS-down

+5V 4.75 5.25 0 6 50MAX red SPS-down

-12V -11.40 -12.60 0 0.1 240MAX blue NON

+3.3V 3.14 3.47 0 6 50MAX orange SPS-down

+5VSB 4.75 5.25 0 1 50MAX Purple SPS-down
