Nano J1900 Icir Itx Embedded Motherboard With Intel Celeron - China

CPU: Integrates Intel® Celeron® J1900 2.0GHz ( max 2.41GHz)

GPU: Integrate Intel HD Graphics

Display output: VGA, built- in VGA pin, HDMI

Memory: 1* SO- DIMM, DDR3L 1333\ 1066MHz Memory, max support up to 8GB

Sound: Onboard Realtek ALC662 HD audio decoding controller

Network: Onboard 2* Realtek RT8111E Gigabit LAN

Storage: 2* SATAoeoe2.5inch notebook hard disk interface

PCI- E: 1* MINI- PCIE 1* MINI- SATA

USB: 1* USB3.0 3* USB2.0 ( 2* USB2.0 need to extend)

COM: 1* COM

Rear I/ O interfae:

1* USB3.0 interface

1* USB2.0 interface

1* VGA interface

1* HDMI interface

1* LAN interface

1* LINE- OUT interface ( support mic)

1* DC interface

Internal I/ O interface:

1* USB2.0 pin ( support extend 2* USB2.0 interface)

1* COM pin

1* F- PANEL pin

1* SYS- FAN pin

1* CPU- FAN pin

1* SATA- PWR pin

1* CLR- COMS jumper

1* F- AUDIO pin

1* VGA pin

1* CIR pin

BIOS: AMI BIOS

Power supply: DC- IN

Cooling system: Main board with CPU radiator

Working condition: - 15~60°C; 0% ~95°C relative humidity, without condensation

Size: 120X120MM
