Cheap 8 4 Inch Dual Core Atom D525 Industrial Panel Pc 800 600 - China

Shenzhen Sunpc Technology Co., Ltd IS a manufactuer and have our own

factory, we provide many kinds of industrial panel pcs , such as

panel mount industrial panel pc, rackmount industrial panel pc, high

performance industrial panel pcs, from 8.4' to 19', and also provide

industrial lcd monitor, fanless embedded computer, mini-itx

motherboard ect

Cheap 8.4' Atom D525 Dual-Core Panel PC IPPC-084D-2R

Feature:

8.4' LCD Panel PC, 800x600 pixels, 250 CD/m2 brightness

Intel Atom D525 dual-core processor 1.8GHz/ with 667 MHz FSB

Resistive Touch screen

Front 6mm Aluminium magnesium alloy with IP65 compliant

Front hardness glass protect screen(touch option)

2*COM, 1*LPT, 2*PS/2, 1*VGA, 4*USB, 2*Glan, 1*Audio, 1*MIC

1*Mini PCI slot

Wireless LAN with antenna (option)

Panel(Flush)mount with Clips

Standard VESA 75mm support stand, Wall mount and swing arm

Specifications;

Display type: 8.4xGA TFT LCD

Screen resolution(Pixels): 800*600

Brightness: 250CD/m2

Contrast Ratio: 500: 1

Pixel Size: 0.297*0.297

Max Color: 16.2MB

Viewing angle: 150(H), 135(V)

Response time: 8ms

LCD MTBF: 50000hrs

Touchscreen: Resistive

Wireless LAN: Meet IEEE802.11B/G standard

I/O:

1*for KB/Mouse

2*100/1000LAN port (RJ-45)

1*VGA

4*USB

2*RS-232, COM2 RS232/422/485

1*Lin-IN/Lin-OUT/MIC-I N

1*Powerr switch

1*DC input connector

System:

Processor: Intel Atom D525(Dual-core 1.8GHz processor) CPU with 67 MHz FSB

Chipset: Intel NM10

Memory; 2*SODIMM DDR3 800/1066/1333 SDRAM up to 4GB

Graphic; Intel GMA 3250 chipset

Storage: Space for 1*2.5' SATA HDD

Ethernet' 100/1000 Ethernet

VGA port' 1*VGA connector

KB&Mouse: 1* port

Audio' Realtek@ALC662, 5.1 Channel surround audio

USB: 4*USB 2.0

Series port; 2*RS232, COM2, RS232/422/485

Expansive slot; 1*Mini PCIe

Environmental;

Construction; Front aluminum bazel and steel enclosure

Operating temperature; 32F~113F (0C ~ 50C)

Storage temperature: -4F~140F (-20C~60C)

Vibration: 17 to 500Hz 1G PTP

Shock: 1G/Peak (11m sec)

Dimension(WHD): 248.8*196.8*670(mm)

G.

W: 3.5KG

Power Supply

Output DC12V@ 1A / 120W external AC Power Adapter with Lockable connector Input 100~240VAC, 50/60Hz

Certificate & Approvals: CE/FCC/ RoHS

Ordering Information

IPPC-084D-2R 8.4' Slim Line Panel Mount Industrial Panel PC with 8.4'touchscreen, Intel Atom D525 Dual-core 1.8GHz Processor, 320G HDD, 2G DDR3 RAM, DC12V power supply

Optional:

Storage: 16G SSD/32G SSD/8G CF card

Wireless LAN: WiFi

Power supply: DC8-28V, DC9-36V

CAN: 2 X CAN
