Te820 Pci Express 8e1 T1 J1 Asterisk Card For Voip Pbx - China

Key features

- - Work on Asterisk/ Trixbox/ Elastix

- - Support zaptel / Dahdi Driver, No need any extra driver patch.

- - 8 E1/ T1/ J1 card

- - ISDN PRI protocol

- - Support SS7

- - PCI- Express interface

- - E1 PRI port total 240 channels

- - Warranty 1 year

Key benefit

- - Creat a wide range of ISDN PRI PBX

- - ISDN least cost router

- - Voice over IP PRI gateways

- - VoIP integration of ISDN equipment

- - PBX to PBX trunking

- - Call center

- - IVR

Discription

- - The TE820 is a octal span, selectable 8T1 ( 24- channel) or E1 ( 32-

channel) card that supports all the functionality of the Digium quad T1/ E1

card.

- - By utilizing our TDMoE technology, an exclusive Digium process, one can

easily connect multiple PCs equipped with the card and achieve voice quality

on par with single PBX implementations.

- - Scalability for this product is derived from adding multiple cards to each

individual PC.

Add addition cards as you need them for your expanding

applications.

- - The card supports industry standard telephony and data protocols,

including both RBS and Primary Rate ISDN ( PRI) protocol families for voice

and PPP, Cisco HDLC, and Frame Relay data modes.

The board drives both line-

side and trunk- side interfaces, including call features.

- - The card is a compact and powerful interface supporting voice and data

transmission over T1, E1, and Primary Rate ISDN ( PRI) connections.

- - The TE820 is a half- length PCI form factor allows this device to fit

within a 2U rackmount case or equivalent chassis, offer excellent density for

call center, service provider, and other space- sensitive applications.

- - The TE820 is fully supported by Digium open source Asterisk PBX software.

Used in conjunction with Asterisk, the card offers the power to create a

seamless network, interconnecting PSTN with the emerging Voice- over IP

technologies.

- - The card can be used to build a wide range of PBX and IVR services to the

network or handset including Three- Way Calling, Call Conferencing, Voicemail

, and VoIP Gateways.

Key benefits

Data Modes

- - Cisco HDLC

- - HDLC

- - PPP

- - Multilink PPP

- - Frame Relay

Voice Modes

- EuroISDN

- AT& R 4ESS

- Lucent 5E

- National ISDN2

dimension& weight

- - Size( mm) : 129* 95* 18mm

- - net weight( g) : 120g

packing

- - Package material: paper box

- - Package Size( mm) : 189* 142* 33

- - Gross Weight( g) : 180g

- - Gross Weight( g) : 180g
