Netlite Handheld Ethernet Tester - China

Netlite Handheld Ethernet tester

Portable Ethernet Tester

Pocket Ethernet Tester Netlite handheld Ethernet tester is portable Ethernet tester for Ethernet troubleshooting and performance measurement, with strong comprehensive functions for network test, can totally meet the testing requirements of Ethernet network deployment, installation, operation and maintenance.

No screen structure, compact and flexible, remote WiFi control by intelligent terminals (mobile phones, tablet PCs, laptops, etc.

) .

In addition, Netlite also provides a wire connection mode.

Netlite support full line rate traffic generation, capture and analysis, support online filter and capture, support RFC2544 test suite, Bert.

Netlite support flexible data packet configurations, single port can generate 64 flows; support a variety of application layer protocol test, best tools for filed installation, maintenance, verify, and troubleshooting.

KEY FEATURES

RFC2544 test; throughput, latency, frame loss and back-to-back

BERT Inline filter and capture, including terminal and through mode

Layer 1~3 loopback testing

Copper TDR testing

SFP DDM

Ping, Arp sweep, Trace route

Configure profile save and load

SPECIFICATIONS

Test port Two 10/100/1000M BASE-T RJ-45 ports; Two 100M/1000M BASE-X SFP optical fiber ports; Support “1 cu port+1 fiber port”, ”2 fiber ports”, ”2 cu ports”, ”single fiber port”, ”1 cu port” five modes

Management port One WiFi, one RJ45(10M)

Power supply One Micro USB

Leds indicate PORT1/2 LINK ACT

error：one yellow

Run：one green, CPU run lighting

Power charge ：one, charging is red, charged full is green

System control One on/off button, one reset button for configuration reset

AC adapt input：100-240VAC, 50-60HZ

output：5V, 2A

Battery 5 hours

temperature -10~45℃

humidity 5%~95%, Non condensation

Dimensions 80x160x35mm

weight 200g

features Client APP mode

RFC2544;throughput, latency, frame loss and back-to-back

Bert

One port 64 streams

Inline filter and capture, support terminal mode and through mode

L1, L2, L3 loopback test

Copper TDR test

SFP DDM

Switch port locate

Ping, ARP sweep, Trace route

Configure file save and load

Ftp/Http/DHCP test

Test result save and output

Buttery management, buttery detect and alarm

System time set

Temperature detect and alarm

Langrage：English/Chi nese

System info check：product mode, hardware version, software version
