Telecommunication With 8 Fxs Port 2 Lan Voip Gateway - China

Product Spotlight

Scicent VoxStack Series Analog Gateway is an industry 1st open source asterisk-based Analog VoIP Gateway solution for SMBs and SOHOs.

With friendly GUI and unique modular design, users may easily setup their customized Gateway.

Also secondary development can be completed through AMI (Asterisk Management Interface).

• Independent System for Each Module

• Affordable Price with Superior Performance

• Hot-swap Design for Modules

• Compatible with Asterisk, Elastix, 3CX, FreeSWITCH Sip Server and VOS VoIP operating platform

• Available for OEM

• 3-Month "No Questions Asked" Return Policy

Overview

There are three Analog Gateway models , the VS-GW1200-8S, the VS-GW1600-8S and VS-GW1600 Analog series.

The VS-GW1600-8S can support 8 FXS ports at the same time, and VS-GW1600 Analog series can support up to 40 FXS ports synchronously.

The Modular Design Analog Gateways are developed for interconnecting a wide selection of codecs including G.

711A, G.

711U, G.

729, G.

722, G.

723, ILBC, GSM.

The Analog Gateways are 100% compatible with Asterisk, Elastix, Trixbox, 3CX FreeSWITCH sip server and VOS VoIP operating platform.

Technical Specifications:

• 8 FXS ports

• 2 LAN ports

• Storage temperature range: -20~70℃

• Operation temperature range: 0~40℃

• Operation humidity range: 10%~90% non-condensing

• Power source: 100-240V/1-2A

• Max power: 60W

• Dimension: 44cm × 4.5cm × 30cm

• Weight: 4353g

Features:

• Simple and convenient configuration via Web GUI

• Abundant Log Info

• Open API interface AMI

• Support T.

38 fax relay and T.

30 fax transparent, can continually fax multiple pages

• Echo cancellation and Static jitter buffer

• Support DTMF relay

• Support Ring cadence and frequency setting

• Support volume control

• Support MWI(Message waiting indicator)

• Support DHCP, DNS/DDNS, NAT networking

• Support diverse SIP protocols

• Diverse extensible applications, such as IVR, DISA

• Support NTP time synchronization and client time synchronization

• Support modify username and password for web login

• Support SSH remote operation

• Support update firmware online

• Support configuration file backup and upload

• Support for custom scripts, dialplans

• Support restore the factory settings

• Support VAD and CNG

Software & Platform:

• Linux

The VS-GW1600 Analog Series Includes The Following Models:

Product Model Description

VS-GW1600-8S 8 FXS ports VoIP Gateway

VS-GW1600-16S 16 FXS ports VoIP Gateway

VS-GW1600-24S 24 FXS ports VoIP Gateway

VS-GW1600-32S 32 FXS ports VoIP Gateway

VS-GW1600-40S 40 FXS ports VoIP Gateway

*One Year Warranty*
