Ceramic Ladder Ring - China

Ceramic Ladder Ring

Ceramic Tower Packing

SPECIFICATION:

Ceramic ladder ring technical data Chemical Composition: SiO2 Al2O3 SiO2+Al2O3 Fe2O3 CaO MgO K2O+Na2O Other

>70% 15-23% >92% <1% <0.25% <0.2% 2-4% <1% Technical specification: Name Specifications Diameter×high ×thick Surface area Void volume Number/volume Drying packing factor mm mm×mm×mm M2/m3 % n/m3 m-1

Ladder ring 25 25×15x3 210 73 74000 540 38 38x23x4 153 75 21600 378 50 50×30x5 108.6 78.7 9091 223 76 76×46x9 63.4 79.5 2517 126

ADVANTAGES:

Ceramic Random Packing, Is widely used in the scrubbing tower, dry tower, absorb tower, colling tower, those are used in chemical, metallurgical, gas, oxygen, medicine, acid, fertilizer and so on.

Advantages: excellent acid resistance and heat resistance.

it can resist to corrosion of various inorganic acid, organic acids and organic solvents except hydrofluoric acid, and can be used in high or low temperature condition.

Ladder Ring(Cascade mini ring), draws the benefits of Rasching ring and Pall ring, the Height-diameter ratio is 1: 2, Because of increasing the Cone flanging, ladder ring can reduce the resistance of gas and the intensity of packing, as well as gas-liquid contact area.

Application: Desulfurization of amine, synthesis of amine decarbonization, common decompression, such as methanol separation, separation of organic acids and so on.
