13x Molecular Sieve Psa Oxygen Industrial 4 8mesh - China

Description:

13X type molecular sieve, also called NaX or NaA type molecular sieve, is one type of alumino silicate crystal with average pores measuring of 9angstrom(0.9nm).

It has good mass transfer rates.

And is commonly used to separate nitrogen from oxygen.

Chemical Molecular Formula:

Na2O·Al2O3·(2.8±0.2 ) SiO2·(6~7)H2O.

(SiO2: Al2O3≈2.6-3.0).

Technical Parameter: Properties Unit Bead Cylinder

Diameter mm 1.6-2.5 3.0-5.0 1.6 3.2

mesh/inch 8*12 4*8 1/16” 1/8”

Bulk density g/ml ≥0.64 ≥0.64 ≥0.61 ≥0.61

Crushing strength N/pce ≥30.0 ≥70.0 ≥30.0 ≥50.0

Size ratio up to grade wt% ≥98.0 ≥98.0 ≥96.0 ≥96.0

Static H2O adsorption wt% ≥25 ≥25 ≥25 ≥25

Static CO2 adsorption wt% ≥17.0 ≥17.0 ≥17.0 ≥17.0

Package Moisture wt% ≤1.5 ≤1.5 ≤1.5 ≤1.5

Wear ratio wt% ≤0.2 ≤0.2 ≤0.40 ≤0.40 Application:

● Remove CO2 and moisture, gas purification in air separation unit.

● Drying and desulfurization of natural gas, liquefied petroleum gas, and liquid hydrocarbons.

● Deeply drying for general gas

● Bulk industrial oxygen in PSA units.

● Desulfurization (sweetening) of natural gas and other fluids Package:

800kg super sack

140kg steel drum

25kg Carton box/Paper drum
