Muffle Furnace Mosi2 Heating Element High Temperature - China

Muffle Furnace MoSi2 Heating Element Vacuum Furnace And Smelting Furnace MoSi2 Heating Element Description: MoSi2 Heating Element is a kind of resistance heating element made from Molybdenum Disilicide.

It can be exerted under the high temperature of the oxidated atmosphere.

MoSi2 heating element rod has the unique function of high temperature anti-oxidation.

Under the oxidated atmosphere, the maximum temperature of MoSi2 elements is 1800°C.

It can be made into various types, including U-type, W-type, right-angle as well as circular type.

Examples: U-Shape, Material Grade 1800, D1=3mm, D2=6mm, Le=140mm, Lu=125mm, A=25mm Specify as: MS18U, 3/6 x 140 x 125 x 25 Oxygen-resistance under high temperature: in oxidizing atmosphere, a layer of compact quartz protective film is formed on the surface of element owing to the high temperature combustion, which prevent Mosi2 from oxidizing more.

When the element temperature is higher than 1700 °C, the film becomes melting.

It’s not suitable for long time use in the temperature range of 400-700°C, otherwise, the element will be powdering for the strong oxidation under low temperature.

Company Contact:

• Posted By: Spark Industry (Henan) Co., Ltd

• Phone: 15664173999

• Address: Rm201 Building 6, South Commercial Zone, Xueqian Rd and 1st South Ring, Dengfeng, Zhengzhou , Henan , China

• Email:

• Website: https://www.resistiveheatingelement.com

• Business Description: Spark Industry (Henan) Co., Ltd. is a comprehensive company specializing in the research and development, production, sales and technical services of silicon carbide and molybdenum disilicide resistance heating elements.

  It adheres to the customer demand orientation, and strives to continuously improve the quality of products and improve services.

  Zhengzhou Songyu High Temperature Technology Co., Ltd., a subsidiary of spark industry (Henan) Co.

  Ltd., is mainly responsible for production and quality inspection.

  The silicon carbide and molybdenum disilicide resistance heating elements produced by our company are sold all over the country, occupying a large share in the domestic market, and exported to the United States, the United Kingdom, Sweden, Germany, Spain, The Czech Republic, Ukraine, Japan, South Korea, India, Australia, new Zealand, Brazil, Mexico, Malaysia, Thailand, Iran, South Africa, Hong Kong, Taiwan and other more than 40 countries and regions, customers include world-renowned multinational manufacturers in various fields.

  In line with the core concept of professionalism, quality, integrity and innovation, we attract all kinds of technical talents and set an example of the highest standards of the same industry in the world to build spark industry into an international well-known industry brand.
