Dh Dl Type Silicon Carbide Electric Heating Element High Temperature - China

Silicon Carbide Heating Element Silicon Carbide Heating Elements is a kind of non-metal high temperature electric heating element.

Silicon Carbide Heating Elements is made of selected high quality green silicon carbide as main material, which is made into blank, siliconization under high temperature and recrystallized.

In oxidizing atmosphere, its service temperature can reach 1450ºC and continuous use life can reach 2000 hours.

Silicon Carbide Heating Elements Applications Electronic industry Metallurgy Al/Zn-industry Ceramic industry Float glass industrya Optical glass industry Laboratory equipment Following are to be provided when making an inquiry or placing an order for Silicon Carbide Heating Elements: Type: DH&DL

Outer Diameter (OD): in or mm, Hot Zone length (HZ) (the heating section): in or mm, Cold Zone length (CZ): in or mm, Shank spacing (A): in or mm

Overall Resistance: Ω 1550 ℃ Silicon Carbide Electric Heating Element Description Product Name: Silicon Carbide Heating Elements Density: 2.8g/Cm³

Material: Silicon Carbide (SiC) Power Source: Electric Power

Shape: ED/U/W/SC/SCR/DB/G/H/DM Working Temperature: Up To 1450℃

Application: Electric Furnaces After-sales Service: Online Support Notice for using 1 - Heater should be protected against damp during storing or installing to ensure the performance of the heater.

2 - In order to be sure of well-distributed lod of each and groups, heater should be divided before assembling.

The tolerance of the resistance of each one cannot exceed by 10% each other.

3 - Heater is hard and brittle, please be careful when assembling and maintaining so as to avoid damage.

4 - When operating the electric furnace at the beginning, the voltage should be increased slowly and cannot be fully loaded at once.

Otherwise the larger current will be resulted in the damage of heater.

5 - When heater is damaged and need to be changed, the resistance of new one should follow the increasing resistance.

6 - SiC heating elements are capable of high power output, and may be mounted either vertically or.

horizontally
