Run Active Anti Swelling Agent In The Oilfields - China

1 - Overview

Run active anti-swelling agent is a new technology product first produced in the world by Suncoo Petrolume Technology Co., Ltd .

Its main ingredient is active inorganic semiconductor superfine grain;it can be widely applied to reservoirs with mudstone repair process and recovery efficiency improvement process.

Compared with other anti-swelling agent, it consider about water damage problem especially for reservoir with mudstone and low permeability reservoirs .

Therefore, the product with active material added can eliminate water damage effectively ; it is a new multi-functional reservoir minerals processing products, developped from brand new visual angle.



2 - Technology Requirements

ITEM RUN-1 active anti-swelling agent RUN-2 active anti-swelling agent

Appearance Light yellow solid Yellow liquid

Surface Tensio mN/M ≤3 5 ≤35

Interfacial tension mN/M ≤1 ≤1

Anti-swelling rate %

Shrinkage expansion depressurization rate %

Permeability recovery value（70℃ 5289; %

3 - Features

(1)The anti-swelling function for channel of swelling clay mineral is double , wash oil function included;

(2)Formation wetted and cleaned, water lock damage eliminated, injection pressure reduced , oil well penetration improved.

(3)The clay suspension particle size become smaller.

(4)Good compatibility with formation water, fresh water

(5)Good compatibility with acidizing liquid , fracturing fluid, surfactant and inorganic salt ;it can be used as preflush of acidification and fracturing process, which produces good synergistic effect.

4 - Applications

Products can be widely used in sensitive reservoir repair processing.

Wells acidification, Blocking removal, sand control , fracturing , oil well washing, all can be applied to.

Usage is 0.5% - 3%; recommended usage is 2.5% to 3%.

Solid RUN - 1 is used in acidization and blocking removal; liquid RUN - 2 is used in fracturing preflush.

5 - Packaging & Storage

Package: Kraft bag with inner lining(Solid RUN-1)

Net weight : 25 kg;

Package: Blue plastic barrels, (Fluid, RUN-2)

Net weight 100 kg or 125 kg;

store in dry and ventilated place;
