Frp Sand Pipe Mould - China
price: 1.00 Dollar US$
FRP sand pipe mould
Product Description
The Fiberglass pipe mould are used in the production of FRP pipes, which can produce pipes with a diameter of 50mm to 4000mm, and can also be developed and produced according to different needs of customers.
Cable duct core mold
specification(mm) specification(mm)
Ø50*L6500 Ø150*L6500
Ø65*L6500 Ø175*L6500
Ø80*L6500 Ø200*L6500
Ø100*L6500 Ø250*L6500
Ø125*L6500 Ø300*L6500
Fiberglass pipe mould
1: Can be made according to user needs
2: Can be produced according to standards specification(mm) specification(mm)
Ø400*L12500 Ø800*L12500
Ø1500*L12500 Ø2500*L12500
Ø500*L12500 Ø900*L12500
Ø1600*L12500 Ø2600*L12500
Ø600*L12500 Ø1000*L12500
Ø2000*L12500 Ø3200*L12500
Ø700*L12500 Ø1200*L12500
Ø2200*L12500 Ø4000*L12500
Ø1400*L12500 Ø1800*L12500
Ø3000*L12500 Ø3500*L12500
The process of making FRP pipes using FRP pipe molds
Production process of FRP pipes
→FRP mold preparation
→Equipment debugging, raw material preparation
→Fiberglass pipe lining production
→Far infrared curing station lining curing
→Quality inspection of glass fiber reinforced plastic pipe lining
→Glass steel pipe reinforced layer winding
→Integral curing of far-infrared pipeline
→Inspection of appearance and main dimensions of FRP pipes
→Glass steel pipe demoulding
→1.5 times the working pressure hydraulic test and other standard requirements
→FRP pipe packaging and storage
Company Contact:
- Phone: 13810023454
- Address: 406, 4th Floor, Building 5, No. 28, Jingsheng South First Street, Tongzhou District, Beijing , Beijing , China
- Email:
- Website: https://www.frpbj.com/
Published date: August 5, 2021
- Business Description: Beijing Xingguangyate Transmission Machinery Equipment Co., Ltd. was established on March 4, 2015 - The company is mainly engaged in the export business of FRP products.
The company puts integrity management and customer service in the first place, and has received general support from the industry in the early stage of development.
And recognition.
With the opportunity of "One Belt One Road", we will seek more overseas partners, and look forward to meeting, cooperating and developing with you.
