Bed Blanket Burning Tester - China

Bed Blanket Burning Tester The test method is to burn the surface of the specimen with a standardized flame for a specified period of time, so that the burning, damage or discoloration of the standard test paper can be observed and the test fabric can be graded.

It conforms to the ASTM D4151-2010 test standard.

Performance parameters.

Test chamber: internal dimensions: height 520mm, width 375mm, depth 220mm.

made of stainless steel, the top 12 12.7mm diameter ventilation holes.

Glass observation window at the front; ASTM D4151-2010 section 6.1 requirements.

Sample mounting base and bracket: ASTM D4151-2010 section 6.2 requirements.

Burner: ASTM D4151-2010 section 6.3 and 6.4 requirements

Burners with 18-gauge needles, as required by ASTM D4151-2010, section 6.3.

Flame measuring scale: measure the flame height of the burner with an accuracy of 1mm.

Pressure gauge: 0~0.25Mpa, accuracy is 0.5 grade.

Control part: meet the requirements of ASTM D4151-2010 6.1.2

Igniter: automatic ignition for high pressure

Combustion timing: 0-99.99s arbitrary setting, resolution is 0.01s, accuracy is 0.1s

Continued combustion timing: 0-99.99s any setting, the resolution is 0.01s, the accuracy is 0.1s

Automatic control: such as ignition, combustion timing, renewal of combustion timing, etc.

Brushing device: in accordance with ASTM D4151-2010 6.5 requirements; by two rows of 0.41mm diameter nylon bristle clusters, each cluster of 20 bristle, every 25mm there are four clusters of two rows of bristle clusters staggered arrangement, bristle clusters flat, the length of 19mm.

ps: (11-17)

ps: (WLJCDM809)
