Iran Diesel Generator Supplier - Iran

HOPI Group Supply the generator from 25kva to 3075 kva that it can make the frame type or canopy type.

we will supply the brand that engine is Cummins , MTU and Caterpillar and alternator is Standford

HOPI Group Supply the Cat generator from 255kva to 2725 kva that it can make the frame type or canopy type.

General Introduction

Caterpillar is the world's largest manufacturer of high-speed diesel packaged generator sets, diesel engines and industrial turbines, with diesel ratings ranging from as small as 275kVA, all the way to as large as 17, 460 kVA.

Cat diesel generator sets are simple to specify and purchase and easy to install and operate, with excellent transient response capabilities and steady state performance.

With its world-class fuel efficiency, Caterpillar is a single source for all your complete power solutions needs with a wide range of factory-designed options.

In all, this translates into lower life-cycle costs for your Caterpillar power systems investment.

FEATURES

FUEL/EMISSIONS STRATEGY

Low fuel consumption

DESIGN CRITERIA

The generator set accepts 100% rated load in one step per NFPA 110 and meets ISO 8528-5 transient response.

FULL RANGE OF ATTACHMENTS

Wide range of bolt-on system expansion attachments, factory designed and tested

Flexible packaging options for easy and cost effective installation

SINGLE-SOURCE SUPPLIER

Fully prototype tested with certified torsional vibration analysis available

CAT SRE GENERATOR

Matched to the performance and output characteristics of Cat engines

Industry leading mechanical and electrical design

Industry leading motor starting capabilities

High Efficiency

CAT EMCP 4 CONTROL PANELS

Simple user friendly interface and navigation

Scabable system to meet a wide range of customer needs

Integrated Control System and Communications Gateway

Genset Type

Power Engine Model Fuel Consumption (L/H) Engine Weight (kg) Dimension L*W*H (mm)



Prime Kw/Kva Standby Kw/Kva Cylinder Bore (mm) Stroke (mm) Displacement(L)



3406 220/275 240/300 3406C 69.3 6L 137 165 14.64 3120 4264×1110×2150

3406 256/320 280/280 3406C 79.6 6L 137 165 14.64 3321 4264×1110×2150

C15 292/365 320/320 C15 75.9 6L 137.2 171.4 15.2 3894 3822×1110×2166

C15 328/410 360/360 C15 92.4 6L 137.2 171.4 15.2 4032 3822×1110×2167

C15 364/455 400/400 C15 97 6L 137.2 171.4 15.2 4032 3822×1110×2168

C15 400/500 440/440 C15 111.8 6L 137.2 171.4 15.2 4160 3822×1110×2169

C18 440/550 484/484 C18 122.8 6L 145 183 18.13 3720 3934×1536×2167

C18 480/600 528/528 C18 135.1 6L 145 183 18.13 3842 3934×1536×2167

C18 508/635 560/560 C18 144.6 6L 145 183 18.13 3987 4234×1536×2168

3412 580/725 640/640 3412C 169.1 12V 137.2 152.4 27.02 5693 4485×1798×1987

3412 648/810 720/720 3412C 191.7 12V 137.2 152.4 27.02 5727 4485×1742×1987

C32 800/1000 880/880 C32 235.3 12V 145 162 32.1 7395 4562×1854×2241

3512 920/1150 1000/1120 3512 259.8 12V 170 190 51.8 12280 5137×1975×2367

3512 1020/1275 1120/1128 3512 297.8 12V 170 190 51.8 12419 5237×1975×2367

3512B 1088/1360 1200/1500 3512B 280.1 12V 170 190 51.8 13204 5241×1975×2342

3512B 1160/1500 1280/1600 3512B 323.3 12V 170 190 51.8 14025 5347×1975×2342

3512BHD 1280/1600 1400/1800 3512BHD 362.7 12V 170 215 58.6 14520 5462×2091×2367

3512BHD 1360/1700 1500/2000 3512BHD 390.9 12V 170 215 58.6 14678 5462×2091×2367

3516 1460/1825 1600/1600 3516 420.9 16V 170 190 69 15375 5909×2286×2342

3516B 1600/2000 1800/1800 3516B 447 16V 170 190 69 16960 6009×2286×2342

3516BHD 1820/2275 2000/2000 3516BHD 501.5 16V 170 215 78 17332 6359×2286×2342

C175-16 2180/2725 2400/3000 C175-16 559.7 16V 175 220 84.67 22103 7786×2089×2211
