Foxboro Scd5200 Remote Terminal Unit - China

DESCRIPTION The SCD5200 is a multi-nodal Remote Terminal Unit with advanced data integration, time synchronization, and programming capabilities.

Its primary slave interfaces are based on the dual communication module which provides DNP3 Slave and IEC 60870- 5-101 Slave functions.

The SCD5200 uses these protocols to communicate and integrate with multiple remote master control centres.

Each SCD5200 rack mounted cardfile can support Power, CPU, Communications and IO modules.

The range of IO modules is extensive, covering all aspects of IO at a wide range of input voltage levels.

Each IO processor is intelligent, providing on board pre-processing and capture of sequence of events information.

REAL-TIME DATABASE AND ENVIRONMENT As shown in Figure 1, the SCD5200 environment consists of a central real-time database which is kept up to date by a variety of independent processes.

These processes are supported by the embedded operating system executive.

IO Time Sync – The real-time clock on each processor is used to synchronize the clocks on all intelligent IO modules.

IDF Intrinsic Data Functions – Event driven preconfigured functionality is very fast and often used for implicit conversions of IO information.

Calculations – Up to 3 calculations tasks can be programmed by the user.

Each task is written as a State Machine or a Procedural Logic using the dedicated State and Logic Language [SALL].
