Galvanized Cast Iron Trailer Hydraulic Disc Brake Caliper - China
price: 30.00 Dollar US$
√ Trailer Brakes √ Hydraulic Trailer Brakes √ Trailer Disc Brakes √ 1400 KG (15”/16” WHEEL) √ Hydraulic Disc Brakes √ 1600 KG (13”/14” WHEEL) √ Trailer Disc Brake Caliper √ Hydraulic Disc Caliper √ Hydraulic Brake Caliper The galvanized trailer hydraulic disc brake caliper is made from cast iron, has a phenolic piston and two pieces of non-asbestos semi-metal brake pads.
Having excellent anti-rust, anti-corrosion, and anti-wear performance.
This trailer hydraulic disc brakes fit the hubs / rotors which have 5 x 4.25” PCD, 5x 4.5” PCD, 5 x 4.75” PCD or 6 x 139.7mm PCD, they suitable for installations where more than one axle is used.
This trailer hydraulic brake caliper applies to boat trailers, caravans, car trailers and box trailers.
The hydraulic brake caliper is easy to install, it can replace the AL-KO hydraulic calipers.
Features l Used with IQ7 or hydraulic over ride couplings (the load weights exceeding 2000 kg).
l Requirement of disc hubs and rotors: Thicknesses from 12 mm to 15 mm.
l Galvanized coated can prevent the corrosion of seawater.
l Mounting bolts, spring washers and pads are included.
Quick and easy installation.
l This hydraulic disc brake calipers exchange with AL-KO and Trojan MK7 calipers, but have different appearance.
Specifications Ø Axle Capability: 1400 kg (15”/16” wheel), 1600 kg (13”/14” wheel) Ø Mounting Bolts: 12mm H.T. x 45mm Ø Bolt Spacings: 88.9mm (3.5”) Ø Recommended operating pressure: 6.9 mpa (1000psi) Product Composition ² Non-asbestos semi-metal brake pads x 2 ² Galvanized Cast Iron Brake Caliper Body x 1 ² Bleed Screw x 1 ² Phenolic Resin Piston x 1 ² Piston Seal x 1 ² Piston Dust Boot x 1 ² Slide Pin Kit x 1 ² Slide Dust Boot x 2
Company Contact:
- Posted By: Tangshan Yingtu Trading Co., Ltd.
- Phone: +863152225139
- Address: HUIJIN CENTER, tangshan , Hebei , China
- Email:
- Website: https://www.trailercaptain.com/
Published date: June 28, 2021 - Modified date: July 26, 2021
- Business Description: Yingtu specializes in offering trailer parts to O.E. and replacement market.
We work mainly on light and heavy duty suspension components, especially Axle, Brake, Caliper and Drum.
With over 10 years experience, our engineer team assure only the best products reach customers.
Engineer team designs and follows each spare part from A to Z.
QC team ensure only the quality products to be packed, to be shipped.
Sales team always responds customers with patience and passion.
All this makes us ideal source for O.
E, distributors, wholesalers and retailers.
