Power Cable For E Bike Motor - China
price: 1.00 Dollar US$
Power cable for E bike motor bafang BBS mid motor
Name power cable
Model WYT-P-*095AT
Inlet/Outlet 2cores /6 cores
Rated voltage 60V AC/DC
Rated current power 15A, signal 2A
Withstand voltage 500V
Insulation resistance ≥20MΩ
Contact resistance ≤10mΩ
Mechanical life 200 times
Insertion force ≤100N
Pull out force ≥50N
Working temperature -25℃～+85℃
Protection grade IP66
Dimensions Male 12.6mm, Female 10mm
Overalllength 75mm
Contact element material gold-plating Copper alloy
Wire specification 2.0mm²+0.20mm²
ATINGS/CHARACTERISTICS
UL Recognized
RoHS Compliant
48 V
1To 3
MATERIAL
FEATURES
Most common Y splitter connector cable for Electric bike.
Lenght: can be any length needed.
Current: 2A
Life: 200 times
1T3
Waterproof cable: IP65 Sealed waterproof connectors, sturdy and durable
ENVIRONMENTS
Ebike controller
Company Contact:
- Posted By: Suzhou Grand Electronic Tech CO., ltd
- Phone: 18758486780
- Address: https://www.szwyte.com/, Suzhou City, Jiangsu Sheng, China
- Email:
- Website: https://www.szwyte.com/
Published date: September 5, 2021
- Business Description: Suzhou Grand Electronic Technology Co., Ltd. is a high-tech enterprise that produces advanced waterproof cables.
It is located in Dongshan Town, Wuzhong District, Suzhou City, China, in the Jiangsu-Zhejiang-Shanghai Economic Triangle.
Grand specialized in integrates research and development, production and sales, and its products are used in professional fields such as new energy vehicles, solar energy, aviation, aerospace, medical care, nuclear technology, and military applications.
Grand has passed the ISO 9001 quality system certification, and its products comply with Chinese and foreign national standards, and have various certificates such as CE, ROSH, etc.
And it has independently developed a number of patented products and has strong independent development capabilities.
