NI PXI-7852R Multifunction Reconfigurable I/O Module Product Overview The NI PXI-7852R is a multifunctional reconfigurable I/O module based on the PXI bus that combines analogue I/O, digital I/O, and a user-programmable FPGA to provide on-board signal processing, custom system timing, and synchronisation.

The module is suitable for test and measurement applications requiring high accuracy, speed and flexibility.

Key Features Analogue I/O: 8 analogue inputs, each with an independent sampling rate of 750kHz, 16-bit resolution and an input voltage range of ±10V.

8 analogue outputs, each with an independent update rate of 1MHz, 16-bit resolution and the same output voltage range of ±10V.

Digital I/O: 96 digital lines, configurable as inputs, outputs, timers or custom logic at rates up to 40MHz.

User-programmable FPGA: Equipped with a Virtex-5 LX50 FPGA, which can be user-programmed with LabVIEW FPGA modules for custom signal processing and on-board decision making.

High-precision Timing and Synchronisation: Provides dedicated features such as multi-rate sampling and independent channel triggering beyond the capabilities of typical data acquisition hardware.

Complete control over the synchronisation and timing of all signals and operations ensures high system accuracy and stability.

High Flexibility: I/O can be reconfigured according to application requirements to meet a variety of test and measurement needs.

Supports a variety of communication protocols and custom protocols to facilitate communication and data exchange with other devices.

Application Scenarios The NI PXI-7852R is suitable for a variety of test and measurement applications, including but not limited to: Hardware-in-the-loop (HIL) testing: for control system testing in automotive, aerospace and other fields.

Custom Protocol Communication: Enables data transfer and exchange for specific communication protocols.

Sensor Simulation: Simulates the output of real sensors for testing and validating control systems.

High-speed control: to achieve high-speed, high-precision motion control and position control.

Software Compatibility NI PXI-7852R is compatible with a variety of software tools, including: LabVIEW: NI's graphical programming environment for rapid development of test and measurement applications.

LabVIEW FPGA Module: for programming and configuring FPGAs for custom signal processing and on-board decision making.

Measurement & Automation Explorer (MAX): Tools for configuring and managing NI hardware devices.

Technical Specifications Axis - Specific Specifications Each axis controlled by the PXI - 7340 has specific technical details.

The maximum speed and acceleration/deceleration capabilities are defined for each axis.

These values depend on the motor - drive characteristics and the load being moved.

The axis also has a specified position - feedback resolution, which is related to the encoder or resolver used.

For example, an axis might have a maximum speed of several thousand revolutions per minute (RPM) and an acceleration rate of a few hundred revolutions per second - squared (), with a position - feedback resolution of a few nanometers.
