Ni Pxi 6608 185745h 02 Timer Module - China

NI PXI-6608 185745H-02 Timer Module Basic Overview Model: 185745H-02 Name: NI PXI-6608 Data Acquisition Module (with timer function) Bus standard: PXI (PCIeXtensions for Instrumentation) Main functions and features Multi-channel acquisition: The module supports multiple independent acquisition channels, allowing simultaneous acquisition of data from multiple signal sources, improving the efficiency and accuracy of data acquisition.

High-speed acquisition capability: With high-speed acquisition capability, it is able to acquire signals and data at a high rate, which is suitable for applications that require fast response and high data flow.

High-precision measurement: Adopts high-precision ADC (analogue-to-digital converter) and measurement technology to ensure the accuracy and reliability of acquired data.

Flexible Configuration and Control: Each channel can be independently configured and controlled to meet different application requirements.

Timer/Counter Function: The module contains timers and counters for time measurement, pulse counting, encoder positioning measurement, event counting, period measurement, pulse width measurement, pulse generation, pulse sequence generation, and frequency measurement.

Multiple interface protocols: Supports a variety of interface protocols, such as GPIB, USB, Ethernet, etc., for easy connection and communication with a variety of instruments and devices.

Programmable control: Support a variety of programming languages and development environments (such as LabVIEW, etc.

), convenient for users to configure, program and control.

At the same time, provide a wealth of debugging tools and functions, convenient for users to carry out troubleshooting and system optimisation.

High Reliability: Adopting high-quality electrical and mechanical components, after strict quality control and testing, to ensure stable and reliable operation under harsh environmental conditions.

Areas of application The modules are suitable for a wide range of applications where precise signal and data measurements are required, e.g. electronic testing, automated testing, biomedical engineering, etc.

In automatic test equipment (ATE), they are used for high-speed data acquisition and signal processing.

In sound and vibration testing, it can be used to acquire and analyse sound and vibration signals.

In machine vision systems, it can be used for high-speed image acquisition and processing.

In communication system testing, it can be used to test and analyse signals in communication systems.

Price and Purchase The price of this module may vary depending on factors such as supplier, purchase channel, and quantity purchased.

It is recommended to consult multiple suppliers for product details, price and after-sales service information before purchase.

FEATURES • Works with all FieldPoint I/O modules (the FP-TB-3 is designed specifically to work with thermocouple I/O modules) • V and C terminals provide external supply voltages common to all channels • DIN-rail mounting or panel mounting • 32 terminals available for field connections (FP-TB-3 has 16) • Available with screw terminals (FP-TB-1 and FP-TB-3) or spring terminals (FP-TB-2) • Isothermal construction (FP-TB-3) minimizes temperature gradients when using thermocouples • –40 to 70 °C operation
