Motor Extension Cable - China
price: 1.00 Dollar US$
Motor Extension Cable, 9 Pin Front Rear Wheel Motor Female to Male
Name Large 9 cores motor cable
Model WYT-PFV2-916AT
Inlet/Outlet 9 cores
Rated voltage 60V AC/DC
Rated current power 20A, cable 2A
Withstand voltage 500V
Insulation resistance ≥20MΩ
Contact resistance ≤10mΩ
Mechanical life 200 times
Insertion force ≤100N
Pull out force ≥50N
Working temperature -25℃～+85℃
Protection grade IP66
Dimensions male 16.8mm, female 16mm
Overalllength 88.5mm
Contact element material gold-plating Copper alloy
Wire specification 2.0mm²+0.20mm²
ATINGS/CHARACTERISTICS
UL Recognized
RoHS Compliant
48 V
power 20A, cable 2A Waterproof cable: IP65 Sealed waterproof connectors, sturdy and durable
MATERIAL
WATER PROOF WIRE FEATURES
Most common Y splitter connector cable for Electric bike.
Lenght: can be any length needed.
power 20A, cable 2A
Life: 200 times
9PIN
Waterproof cable: IP65 Sealed waterproof connectors, sturdy and durable
WATER PROOF WIRE ENVIRONMENTS
Ebike motor
