Sw83a Beta And Radiometer Dosimeter - China

SW83A - Ⅱ beta, gamma radiation individual alarming device built-in reform counter high sensitivity detector, it is mainly used to monitor various radioactive workplace χ, gamma and beta radiation, it has fast response, wide measuring range.

It can display the workplace dose equivalent rate and cumulative dose, replace the battery.

When the calendar, time and accumulated data can be stored permanently.

It is widely used in nuclear power plants, accelerator, steel, chemical, industrial Χ, gamma, isotope application nondestructive flaw detection, radiation health, cobalt source treatment, nuclear radiation, radioactive lab, environment monitoring and staff in the field of personal safety protection monitoring and prompt.

Applications

1 - Unknown radiation survey

2 - Environmental laboratory, environmental pollution investigation

3 - Nuclear medicine, meristematic biology, radiation chemistry

4 - Import and export commodity inspection

5 - Indoor environment and building materials test

6 - Irradiation processing, nondestructive flaw detection

7 - Nuclear safety emergency Features

1 - effective GM tube detector, beta, gamma rays, can be obtained

2 - the operation is simple, easy to carry

3 - indicates a radioactive intensity of sound frequency

4 - Alarm can be set up dose rate and cumulative dose alarm threshold

5 - super-low function design, high sensitivity, this bottom can be measured on the environment

6 - in English and Japanese interface

7 .

units according to the CPS, mu, mu Sv/h R/h

8 .

super threshold alarm

9 .

battery real-time instructions

10 - can be connected via USB and computer, realizing the online edit instrument data read

11 .

can save historical data Specifications: 1 - Measuring range: 0-500000 CPM, 0-8000-0.01-10000 CPS mu Sv/h

2 - Cumulative dose, 0.01 mu Sv - 9999 MSV

3 - Energy ranges: 40Kev～3.0Mev

4, instrument counts per minute: <=30CPM

5 - Energy dependence: ≤±25%(relative to 137Cs)

6 - Relative errors : ≤±10%

7 - Sensitivity: > 6000 c/uSv

8 - Alarm reaction time: <=5 seconds( the greater the dose rate the faster response time)

9 - Alarm threshold dose rate: 0.5, 1.00, 1.050, 2.00, 2.50, 5.00, 10.00, 50.00, 100 mu of Sv/h

10 - Cumulative dose alarm threshold value: 0.05, 0.50, 1.00, 2.00, 5.00, 10.00, 5.00, 10.00 mSv

11 - Power supply: 2 section 5 batteries or rechargeable batteries

12 - Power consumption: the machine power consumption about 8 mw, current or less 4 ma

13 - Temperature range: relative humidity: 15 ℃ -50 ℃

14 - Humidity range: relative humidity of 90% or less (40 ℃)

15 - Size weight: 0.3 kg; 135 * 70 * 25 mm Dear Mr Leandro Faria, Good day!

Last letter you told me you want to find dosimeter that is able to store the data, and pass to a PC.

Now I recommend you our SW83A- β and γ radiation .

It can measure beta particles flux density and gamma radiation ambient dose equivalent.

It can store 400 set of historical data.

It can pass to PC.

Following is our quotations:

1 - Price: US$/set with ecourier fee.

2 - Payment: 30%TT in advance, balance should be paid the shiment.

3 - Transportation Mode: By air cargo.

4 - Price valid: Within 15 days.

You can see clearly specifications and quotation in attached files.

Pls check it carefully.

Any more questions, pls feel free to contact me

Best regards, Monica
