Hby Textile Moisture Water Vapor Transmittance Tester - China

HBY textile moisture permeability tester textile water vapor transmittance tester HBY textile moisture permeability tester is used to measure the moisture permeability of various fabrics (including moisture permeable coated fabrics) such as medical protective clothing and assault clothing, as well as clothing non-woven fabrics such as cotton wadding and space cotton

Compliance with standards:

GB 19082-2009 technical requirements and test methods of disposable medical protective clothing

Gb/t 12704.1-2009 textiles test method for moisture permeability of fabrics Part 1: moisture absorption method

Gb/t 12704.2-2009 textiles test method for moisture permeability of fabrics Part 2: Evaporation Method ASTM E90, JIS l1099a, BS 7209, JIS l1099b

Technical parameters:

1 - Touch screen control, Chinese and English menus, man-machine dialogue mode, convenient operation.

2 - High precision temperature and humidity sensor, PID algorithm is used for control, and the fluctuation is small, which can effectively prevent the overshoot of temperature and humidity.

3 - With temperature and humidity calibration function, it can well avoid sensor deviation caused by long-term use.

4 - PLC control, color touch screen operation, modular design, temperature and humidity digital setting, intelligent control, real-time display of temperature and humidity and timing time.

Heat dissipation mode: air cooling

5 - Input parameters on the touch screen and calculate WVT g/ (H.

M) ²), WVP g/(h.

mmHg.

m ²), PV, g.

cm/(h.

mmHg.

m ²) Value.

6 - The instrument can record the temperature and humidity curve, which is convenient for the calculation and printing of a large number of data reports.

With a micro printer, it is suitable for a variety of standards and measurement methods.

7 - Adjustable temperature control accuracy / resolution: -40 ~ 150 ℃ ± 0.5 ℃ / ± 0.1 ℃

8 - Adjustable humidity relative humidity: 20 ~ 98% RH; ±2%RH

9 - Air velocity in the box: 0.1 ~ 0.8m/s

10 - Configuration: 1 Number of layers and number of moisture permeable cups: 4 single layers (national standard)

Qinsun fabric testing equipment suppliers provide premier textile testing instruments and many types of textile testing methods.

Welcome to leave a message and order!

PS: (WLJCDM809-W)
