Uv Radiation Aging Tester Manufacturer - China

UV radiation aging tester The UV irradiation aging box is a kind of equipment that mainly focuses on light, so it can also be called the UV aging test box, but its function is not only the lighting function, but also can choose to add the spray function to simulate the rainy weather and increase the The condensation function simulates hot and humid climates or dewdrop climates, because the outdoor climate is diverse, sometimes the sun is out, sometimes it is humid in the afternoon, so it is also a test equipment that can simulate a comprehensive climate for aging.

Ultraviolet irradiation aging box is widely used in plastics, coatings, paints, rubber materials, glass, decorative boards, aviation, optoelectronic products, industrial fabrics, surface laminations, and colored products to simulate artificial aging in the environment of sunlight, rain, and dew.

Accelerated aging test.

It is used to evaluate the changes of related materials in terms of fading, color change, gloss, cracking, embrittlement, blistering, oxidation, etc.

Main technical indicators of UV irradiation aging box: 1 - Condensation cycle temperature control range: 40 ~ 60 ℃; 2 - Light cycle temperature control range: RT+10℃～70℃; 3 - Temperature uniformity: ±3℃ 4 - Condensation: Vapor Condensation 5 - Illumination/condensation cycle: 0～9999 hours can be set (such as 4H/4H or 8H/4H) 6 - Lamp center distance: 70mm 7 - The distance between the sample and the tube plane: 55mm 8 - UV lamp: UV-A340 9 - Ultraviolet wavelength: UVA315～400nm or UVBUVA280～340nm 10 - Irradiation intensity: adjustable from 0.1 to 1W/m2@340nm 11 - Lamp life: 1600～1800H 12 - Spray cycle: 0 to 9999 minutes (can be set) 13 - Standard test piece: 75mm*140mm or customized according to customer requirements (48 samples can be tested) 14 - Control system: programmable system, Taiwan programmable 7-inch true color touch screen controller (QTEST), Chinese operation interface, easy to use.

14 - Power supply: AC220V 50HZ 4.7KW Structure and material: 1 - Studio size: 450×1165×500㎜ (D×W×H) 2 - Dimensions: 500×1300×1400㎜ (D×W×H) 3 - Liner material: SUS304# stainless steel plate 4 - Shell material: high-grade stainless steel plate 5 - Test piece fixture material: SUS304 stainless steel plate 6 - Ultraviolet lamps: 8 pieces in the second row, 40W/piece Recommended mask testing equipment: Weathering / Corrosion Chamber Horizontal Vertical Flammability Tester Taber reciprocating abraser tester Respiratory Resistance Tester PS: (WLJCDM809-W)
